產品展示
高溫?zé)o紡布膠帶Intertape 51595 膠帶
點擊次數：0發布時間：2025/3/14 17:30:02
更新日期：2025/3/14 17:30:02
所 在 地：中國大陸
產品型號：51595
優質供應
詳細內容
用于電機變壓器等包扎絕緣
ntertape polymer group
POLYESTER FILM / POLYESTER NON-WOVEN ELECTRICAL TAPE
Description
The combination of Polyester Film ａnd Polyester Non-Woven Materials can be used in a wide variety of electrical applications. Acrylic adhesive system combination of tear ａnd puncture resistance, high tensile strength with elongation, ａnd excellent dielectric strength.
PRODUCT APPLICATIONS
Ideal for high volume coil wrapping applications, ground ａnd barrier insulation, outer protective wrap for bobbin applications, coil end insulation anchoring leads ａnd terminal boards.
NOMINAL VALUES
ntertape polymer group
POLYESTER FILM / POLYESTER NON-WOVEN ELECTRICAL TAPE
Description
The combination of Polyester Film ａnd Polyester Non-Woven Materials can be used in a wide variety of electrical applications. Acrylic adhesive system combination of tear ａnd puncture resistance, high tensile strength with elongation, ａnd excellent dielectric strength.
PRODUCT APPLICATIONS
Ideal for high volume coil wrapping applications, ground ａnd barrier insulation, outer protective wrap for bobbin applications, coil end insulation anchoring leads ａnd terminal boards.
NOMINAL VALUES
The following data are nominal values based on PSTC, ASTM ａnd other standard test. The data should not be considered as specifications.
Backing Thickness: 3.5mil (0.089mm)
Adhesive: Acrylic
Color: white
Total Thickness: 4.5mil (0.114mm)
Dielectric Strength 2 : 5000 Volts
Temp. Class 2 :155 C / F
Insulation Resistance 2 :10 5 megohms
Tensile Strength: 30 lbs/in (52 N/cm)
Adhesion to Steel :50 oz/in (5.5 N/cm)
Elongation : 30%
Electrolytic Corrosion :1.0 Direct/ A, 1*
Flammability :BU 2*
Storage Stability : Excellent
Solvent Resistance: Excellent
Moisture Resistance : Excellent
UL File # : E20780
CSA File #: LR94980
