美國生產(chǎn)，“君達(dá)”代理，常備庫存，各種寬度可裁切，特意為親定做的寬度不能退貨喲。

全新原裝正品 NITTO高溫玻璃纖維膠帶P-212 代理 PERMACEL

P-212 GLASS CLOTHELECTRICAL INSULATING TAPE

美國高溫玻璃纖維布膠帶P-212

APPLICATIONOur highest thermal-rated glass cloth tape.Premium tape for use wherever superior solvent resistance ａnd flameretardancy are required.Used for insulating coil connections ａnd coil ends,and as terminal board pads ａnd coil outer wraps.Also,for holding coilleads ａnd anchoring terminal boards;for sealing ａnd enclosing hermetically-packaged components;and,for making motorlead ａnd internal connections,slot cell edge taping,and cable harness wrapping.Recommended for general-purpose insulating ａnd holding applications involving heavy-gauge wire and/or high temperatures.FEATURES AND BENEFITS• High thermal rating,flame retardancy ａnd superior conformability make P-212 ideal in high temperature cable harnesses ａnd connection insulating applications.• Excellent edge tear resistance.• Offers superior solvent resistance.TECHNICAL DATAInsulation classBacking materialAdhesiveColorTotal tape thicknessAdhesion to steelTensile strengthDielectric strengthElongationFlammability ratingUL component recog.Gov’t specificationNote:The above are typical values ａnd should not be used in writing specifications.STOCK SIZESRefer to current Electrical Division Price List.

200 ° C Glass clothSiliconeWhite7.5 mils/0.191 mm40 oz.per in./445 gm per cm190 lbs.per in./34.2 kg per cm3,500 volts7%Passes UL 510 Flame TestGuide OANZ2,File E20392Fungus resistance MIL-I-4053;MIL-I-19166C,7 MIL
